Blauberg Turbo G Mixed Flow Fan - 300MM (12" Inch) | 1030CFM | Thermostat | Speed Control

#SKU: FAN1004
Brand: Blauberg
View PDF brochure for Blauberg Turbo G Mixed Flow Fan - 300MM (12" Inch) | 1030CFM | Thermostat | Speed Control Download PDF brochure
$649.95

Availability: In Stock at Lidcombe Warehouse
Delivery Method: Free Shipping or Free Pick Up


Calculate Shipping


Description



The Blauberg Turbo G Mixed Flow Fan is the best ventilation solution for premises requiring permanent temperature control as greenhouses, orangeries, etc.

Complete with 4 metre wired thermo probe for accurate temperature readings.

Operating the fan speed controller and thermostat:

  • Set your desired grow room temperature on the thermostat (e.g. 20 degrees celsius)
  • Set the desired speed you wish the fan to run (e.g. medium speed)

When your grow room temperature drops below the set temperature on the thermostat (20 degrees celsius), the fan will operate at the selected speed (medium). When the temperature rises above the selected temperature, the fan will increase its speed to maximum until the temperature drops again to the desired level.

This means that when the area cools down, the fan will then also slow down reducing overcooling.



Features



These Blaubergs mixed flow fans offer a range of features including;

  • Casing made of low flammable polypropylene
  • Single-phase motor on ball bearings
  • Equipped with thermal overload protection with automatic restart
  • Automatic speed control depending on indoor temperature with thermostat





Specifications



Parameter Value
Phase, [˜] 1
Voltage, [V] 230
Frequency, [Hz] 50/60
Power, [W] (min) 227
Power, [W] (max) 315
Current, [A] (min) 0.99
Current, [A] (max) 1.42
Maximum air capacity, [m³/h] (min) 1420
Maximum air capacity, [m³/h] (max) 1750
RPM, [min-¹] (min) 2115
RPM, [min-¹] (max) 2505
Sound pressure level at 3 m distance, [dBA] (min) 47
Sound pressure level at 3 m distance, [dBA] (max) 56
Max. operating temperature, [°C] 60
Ingress protection rating IP X4





Type Dimensions [mm] Weight
[kg]
D D1 B H L
Turbo 315 310 323 362 408 445 11.7









These Blaubergs mixed flow fans offer a range of features including;

  • Casing made of low flammable polypropylene
  • Single-phase motor on ball bearings
  • Equipped with thermal overload protection with automatic restart
  • Automatic speed control depending on indoor temperature with thermostat
  • [1] x Blauberg Turbo G Mixed Flow Fan - 300MM (12" Inch) | 1030CFM | Thermostat | Speed Control

Mounting

  • Due to compact design the fan is the ideal solution for mounting in limited spaces, including space behind a false ceiling.
  • The fan can be installed in any section of the ventilation system from intake to the end of the ductworks.
  • Wall or ceiling mounting with a mounting plate.







Parameter Value
Phase, [˜] 1
Voltage, [V] 230
Frequency, [Hz] 50/60
Power, [W] (min) 227
Power, [W] (max) 315
Current, [A] (min) 0.99
Current, [A] (max) 1.42
Maximum air capacity, [m³/h] (min) 1420
Maximum air capacity, [m³/h] (max) 1750
RPM, [min-¹] (min) 2115
RPM, [min-¹] (max) 2505
Sound pressure level at 3 m distance, [dBA] (min) 47
Sound pressure level at 3 m distance, [dBA] (max) 56
Max. operating temperature, [°C] 60
Ingress protection rating IP X4





Type Dimensions [mm] Weight
[kg]
D D1 B H L
Turbo 315 310 323 362 408 445 11.7





SKU FAN1004
Barcode # 4046634014804
Brand Blauberg
Shipping Weight 12.5000kg
Shipping Width 0.400m
Shipping Height 0.350m
Shipping Length 0.400m
Shipping Cubic 0.056000m3
Unit Of Measure ea
